Polyphthalamide
Amodel® AS-1933 HS
Amodel® AS-1933 HS is a 33% glass reinforced grade of polyphthalamide (PPA) resin developed specifically for improved performance in a 50/50 ethylene glycol and water environment. This material exceeds the performance required by the automotive industry for polymeric materials exposed to antifreeze at 226°F (108°C), even when tested at 275°F (135°C).
Potential applications include a variety of automotive components such as thermostat housings, heater core endcaps, heater hose connectors, and water inlets, outlets and valves.
- Black: AS-1933 HS BK 324
Processes
- Injection Mold Tooling & Parts
Features
- Antifreeze Resistant
- Chemical Resistant
- Creep Resistant
- Good Dimensional Stability
- Good Glycol Resistance
- Good Stiffness
- Heat Stabilized
- High Heat Resistance
- High Strength
Applications
- Automotive Applications
- Automotive Under the Hood
- Housings
- Industrial Applications
- Industrial Parts
- Machine/Mechanical Parts
- Metal Replacement
- Power/Other Tools
Properties
General | ||||
Material Status
|
|
|||
Availability
|
|
|||
Filler / Reinforcement
|
|
|||
Additive
|
|
|||
Features
|
|
|||
Uses
|
|
|||
RoHS Compliance
|
|
|||
Appearance
|
|
|||
Forms
|
|
|||
Processing Method
|
|
|||
Multi-Point Data
|
|
Mechanical |
Nominal Value
|
Unit
|
Test Method
|
Tensile Modulus
|
|||
—
|
1.70E+6
|
psi
|
ASTM D638 |
— 3
|
1.10E+6
|
psi
|
ASTM D638 |
—
|
1.83E+6
|
psi
|
ISO 527-1 |
Tensile Strength
|
|||
Break
|
32000
|
psi
|
ASTM D638 |
Break 3
|
11000
|
psi
|
ASTM D638 |
Break
|
30700
|
psi
|
ISO 527-2 |
Tensile Elongation (Break)
|
2.5
|
%
|
ASTM D638, ISO 527-2 |
Flexural Modulus
|
|||
—
|
1.56E+6
|
psi
|
ASTM D790 |
—
|
1.54E+6
|
psi
|
ISO 178 |
Flexural Stress
|
|||
—
|
44800
|
psi
|
ISO 178 |
Yield
|
45400
|
psi
|
Thermal |
Nominal Value
|
Unit
|
Test Method
|
Deflection Temperature Under Load
|
|||
264 psi, Unannealed
|
530
|
°F
|
ASTM D648 |
264 psi, Unannealed
|
532
|
°F
|
ISO 75-2/Af |
Melting Temperature
|
594
|
°F
|
ISO 11357-3 |
Injection |
Nominal Value
|
Unit
|
Drying Temperature
|
250
|
°F
|
Drying Time
|
4.0
|
hr
|
Suggested Max Moisture
|
0.030 to 0.060
|
%
|
Hopper Temperature
|
175
|
°F
|
Rear Temperature
|
580 to 605
|
°F
|
Front Temperature
|
600 to 625
|
°F
|
Processing (Melt) Temp
|
610 to 650
|
°F
|
Mold Temperature
|
275
|
°F
|
Notes |
3After Immersion in 50/50 Glycol/Water Mixture for 1,000 hours at 275°F (135°C) |
